Specification
Engine
Type: 4-Stroke - OHV / 1 Cylinder
Displacement: 393 cc
Bore and Stroke: 84.5 x 70
Compression Ratio: 9.3 : 1
Fuel System: Delphi EFI
Cooling: Liquid
Starting System: Electronic
Drive Train
Transmission: Automatic CVT
Drive System: On Demand 2WD / 4WD with Locking Differential - F N R
Final Drive: Shaft Drive
Chassis / Suspension / Brakes
Suspension Front: Independent dual A-arm with Anti-sway system
Suspension Rear: Swing Arm
Brakes Front: Dual Ventilated Hydraulic Disc
Brakes Rear: Single Ventilated Hydraulic Disc
Tires / Front: AT25 x 8 –12 Radial
Tires / Rear: AT25 x 10 –12 Radial
Dimensions
L x W x H: 82.5" x 42" x 46"
Wheelbase: 51.5"
Fuel Capacity: 10 L
Vehicle Weight: 673 lbs
Cargo Bed Capacity: 44 lbs Front Rack / 77 lbs Rear Rack
Towing Capacity: 500 kg
Ground Clearance: 8"
Other
Instrumentation: Digital Display, LED Lighting, Front and Rear Cargo Racks, 2500 lb Winch
Available Colors: Camo, Dark Green, Red
Compliance: EPA / CARB
Warranty: 2 Year Factory
Highlights:
Liquid Cooled EFI Engine
On Demand 4-Wheel Drive
Column Shift F/N/R
Establishing a great reputation can be tough, but that’s what Hisun ATV’s have been doing for years. Great reputations can only be gained by traveling the toughest trials and completing the most daunting tasks. Hisun ATV’s are up for the challenge. An electronic fuel injected engine is at the heart of every one of our Utility ATV’s transferring its power through an automatic CVT drive system. Hisun ATV’s will take you to places you’ve only dreamed without taking your wallet for a ride.
