Specification
Engine
Type: EFI 4-Stroke - OHV / 1 Cylinder
Displacement: 735 cc
Bore and Stroke: 102 x 90
Compression Ratio: 9.7 : 1
Fuel System: Electronic Fuel Injection
Cooling: Liquid
Starting System: Electronic
Drive Train
Transmission: Automatic CVT
Drive System: 4WD with Locking Differential - F N R
Final Drive: Shaft Drive
Chassis / Suspension / Brakes
Suspension Front: Independent Double Swing Arm
Suspension Rear: Independent Double Swing Arm
Brakes Front: Dual Ventilated Hydraulic Disc
Brakes Rear: Dual Ventilated Hydraulic Disc
Tires / Front: AT26 x 9 –12 Radial
Tires / Rear: AT26 x 11 –12 Radial
Dimensions
L x W x H: 92.3" x 50.3" x 54.3"
Wheelbase: 57.2"
Fuel Capacity: 13 L
Vehicle Weight:853 lbs
Cargo Bed Capacity: 44 lbs Front Rack / 77 lbs Rear Rack
Towing Capacity: 550 KGS
Ground Clearance: 11.6"
Other
Instrumentation: Digital Display
Available Colors: White, Black, Blue, Red, Orange, Vista Camo
Accessories: LED Lighting, Front and Rear Cargo Racks
Compliance: EPA / CARB
Warranty: 1 Year Factory
Highlights:
Liquid Cooled EFI Engine
4 Wheel Drive
Column Shift L/H/N/R
Establishing a great reputation can be tough, but that’s what Hisun ATV’s have been doing for years. Great reputations can only be gained by traveling the toughest trials and completing the most daunting tasks. Hisun ATV’s are up for the challenge. An electronic fuel injected engine is at the heart of every one of our Utility ATV’s transferring its power through an automatic CVT drive system. Hisun ATV’s will take you to places you’ve only dreamed without taking your wallet for a ride.
